SIVACON is tailored to the needs of the world market, i.e. it takes into account the call for standard solutions from a single source on the one hand and on the other for local production and the resulting advantages in terms of financing and procurement close to the plant.

As a power distribution board, SIVACON is available throughout the world and can be used at all power levels up to 7400 A, as withdrawable as well as plug-in and fixed-mounted units.

• Type-tested standard modules

(TTA)

• Standardized busbar position at the top of the cubicle

• 3- and 4-pole busbar system up to 7400 A

• Rated peak withstand current Ipk up to 375 kA

• Deep switchgear compartment for universal installation Modular structure of device compartments

• Single-front and back-to-back installation

• Cable lead-in from above or below

• Cable connection from the front or rear

Modular technology makes it possible to adapt SIVACON optimally to all requirements.

• Standard horizontal busbar position at the top of the cubicle

• Any components can be installed in the device compartments regardless of the busbar position and cubicle depth

• Requirement-oriented compartmentalization of functional units (Form 1 to Form 4 according to IEC 60439-1)

• Deep device compartments

The frame consists of rigid sheet steel sections that are linked to one another: SIVACON's dimensionally accurate and sturdy frame is available in bolted or welded versions.

Surface Treatment:

Optionally powder-coated, wetpainted or sendzimir-galvanized

Frame and enclosure are manufactured from sheet steel in the following thicknesses:

Frame: 2.5 mm

Enclosure: 2.0 mm

Degrees of Protection to IEC 60529 IP 30, IP 31, IP 40, IP41, IP 42 naturally ventilated IP 40, IP 54 unventilated

Differing requirements for the busbar system call for individual options.
